Wipan Lock
1 / 5
| Model no. | E0215-MB-CKY |
| Lockcase |
|
| Unlocking method | Key, password, bluetooth |
| Door Thickness | Standard 35 to 50mm (1.38 ~ 1.97") |
| Backset | The standard adjustable backset 60mm or 70mm (2-3/4"). |
| Material | Zinc Alloy / ABS |
| Battery | 6V (4 * AA batteries) |
| Standby Current | < 40 mA |
| Action Current | < 400 mA |
| Password capacity | 150 pcs |
| Alarm Voltage | 4.5 ~ 6.5V |
| Capacity after alarm | 100 pcs |
| Work Temperature | -30°C ~ 65°C |
| Relative humidity | 5% ~ 95% |
| Antistatic | Contact discharge > ±8kv; Air discharge > ±15kv; |
| Battery Life | 12 - 15 months |
A1: This lock features a triple-unlock mechanism, allowing you to access via physical Key, Password, or Bluetooth connection.
A2: It fits a standard door thickness of 35mm to 50mm (1.38" to 1.97") and supports an adjustable backset of 60mm or 70mm (2-3/4").
A3: The lock operates on a 6V power system requiring 4 standard AA batteries. The battery lifespan typically lasts between 12 to 15 months under normal use.
A4: The system has a standard capacity of 150 password slots, and supports a safe capacity of 100 slots after an alarm threshold is triggered.
A5: Yes, it is designed to withstand a wide temperature range from -30°C up to 65°C, and relative humidity levels between 5% and 95%.
A6: The lock is equipped with an emergency escape function, an anti-insert function, a split shifting plate, and an activity latch bolt that automatically accommodates left and right door configurations.
